| Technical Data |
Cutting capacity(mm) |
300mm for Round shape, 300WX500H for square shape |
| Blade speed(m/min) |
25/36/47/58/80 |
| Blade size(mm) |
0.9×27×3620 |
| Main Motor(kw) |
2.2 |
| Hydraulic Motor(kw) |
0.75 |
| Work piece Clamping |
Hydraulic Vise |
| Blade Tension |
manual |
| Main Drive |
Worm wheel drive |
| Material feed |
Manual |
| Machine size |
1970×1320×1580 |
| Machine weight |
800kg |
| Standard Equipment |
Blade cleaning brush |
Power blade cleaning brush |
| Working light |
YES |
| One piece of bi-metal saw blade |
YES |
| One set of tools with tool box |
YES |
| Operation manual |
YES |
| Out feed with auxiliary plate table |
YES |
| Length stopper |
YES |
| Manual work height control |
YES |
| Machine package |
Steel and plywood |
