| Technical Data |
Cutting capacity(mm) |
350mm for Round shape, 350WX450H for square shape |
| Blade speed(m/min) |
25/33/53/80 |
| Blade size(mm) |
1.1×34×4115 |
| Main Motor(kw) |
3 |
| Hydraulic Motor(kw) |
0.75 |
| Work piece Clamping |
Hydraulic Vise |
| Blade Tension |
manual |
| Main Drive |
Worm wheel drive |
| Material feed |
Manual |
| Machine size |
2200×1400×1580 |
| Machine weight |
900kg |
| Standard Equipment |
Blade cleaning brush |
Power blade cleaning brush |
| Working light |
YES |
| One piece of bi-metal saw blade |
YES |
| One set of tools with tool box |
YES |
| Operation manual |
YES |
| Out feed with auxiliary plate table |
YES |
| Length stopper |
YES |
| Manual work height control |
YES |
| Machine package |
Steel and plywood |
|---|
| Option parts |
1.Hydraulic blade tension |
| 2. 1m Roller table |
3. Band saw blade |
