| Model No. | New | CH-500 |
|---|---|---|
| Max Diameter | ● | 500mm |
| ■ | 500×500mm | |
| Blade | Speed | 25/45/75 m/min |
| Size | 41×1.25×5450mm | |
| Tension | Manual | |
| Motor power | Blade | 4kw |
| Hydraulic | 1.1kw | |
| Coolant | 0.06kw | |
| Chip Clean | manual | |
| Workpiece Clamp | Hydraulic | |
| Machine weight | 2010kg | |
| Machine size(L×W×H) | 2635×1210×1885 | |
| Machine parts: 1> saw blade:1 cps 2> tools: 1 set 3> 1m roller table 1 set 4>manual insutruction 1 pcs | ||
