| Model | LYQ-40 |
|---|---|
| Cut-off capacity(mm) | φ40 |
| Cutting capacity(s/min) | 45 |
| Keep-off range(mm) | 20-300 |
| Screw feeding accuracy | ≤2 |
| The section roundness | 0.95 |
| Shear weight error(g) | ±1 |
| Motor(kw) | 5.5 |
| Weight(kg) | 1500 |
| Cutting range | |
| Material | Cut-off capacity(mm) Round Bar |
| 20# Q235 | φ45 |
| 20MN 20Cr | φ42 |
| 45# 1Cr13 40MN | φ40 |
| 55# 40Cr 20CrMnTi 2Cr13 | φ30 |
| 35CrMo 3Cr13 | φ28 |
| 42CrMo GCr15 60CrMn | φ26 |
